50x50mm Galvainzed Based Rock Wool Insulation Pin With Self Locking Washer

Name: 50x50mm Galvainzed Based Rock Wool Insulation Pin With Self Locking Washer
Brand: XIANGYI
Price: 0.1 USD

50x50mm Galvainzed Based Rock Wool Insulation Pin With Self Locking Washer Manufactures

Brand Name : XIANGYI

Model Number : Rock wool insulation pin

Certification : ISO9001-2015

Place of Origin : HEBEI

MOQ : 30.000 PCS

Price : USD 0.1-0.35 per pcs

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 100.000 PCS PER WEEK

Delivery Time : within 15 days after confirm the order

Packaging Details : 1.500/1000 PCS in one carton 2. on pallet 3. to be request

Product Name : Rock wool insulation pin

Material : carbon steel ,stainless steel ,aluminum

Base Plate : 50mmx50mm

Pin diameter : 2.7mm,3.0mm

Pin length : 38mm;43mm;53mm;63mm,115mm, 130mm, 150mm, 164mm, 180mm, 203mm

Sample : Free

Label : Support

Usage : Fixing rock wool

Contact Now

**50*50 Mm Galvainzed Based Rock Wool Insulation Pin With Self-Locking Washer**

Rock Wool Insulation Pin Basis Information :

self adhesive insulation pin are used for fixing insulation materials on vertical application surfaces. Self-adhesive

standard insulation pins can be used only on straight, smooth, clean and dry surfaces. Adhesive Surface must

not be fingered. Insulation pin have a sticker backing to make placing easier. They also have a unique Easy-Peel

adhesive backing design so that there isn't any fumbling with the release paper.

self adhesive insulation pin are widely used for metal buildings, concrete foundations - even to the underside

of wooden roofs.

Rock Wool Insulation Pin Specification :

Product name:	Rock wool insulation pin
Model Number:	ms-50
Advantage:	good quality and low price
Application:	Fixing rock wool
usage:	HVAC system, Air conditioning
Base Gasket:	Double Sided PE Foam
Base Material:	Galvanized Steel
Base Plate Size:	2" x 2" (50X50)
Head Diameter:	2.7mm,3.0mm
Finish:	Galvanized insulation pin
Glue:	Against High Temperature 90℃
Length:	38mm-230mm
Nail Length in common	38mm;43mm;53mm;63mm,115mm, 130mm, 150mm, 164mm, 180mm, 203mm
Lock washer Dia.:	38mm/40mm/50mm
Material:	Steel, Nail:Aluminium alloy;Base:Hot Galvanized Steel Sheet
PACKING:	500 pcs or 1000 pcs in carton on pallet
sample:	free
Type:	rock wool stick pin
Washer	round self locking washers

Rock Wool Insulation Pin Pic :

XY PARTS Company introuduce:

Hebei Xiangyi metal products company is a insulation fasteners/insulation anchors manufacturing company,

we produce all kinds of insulation pins and washers.can make mold according your drawing pic ,Our products

is as following :

CD weld pins Lacing Anchors

bimetallic pin Cup head weld pins

Quilting pins perforated base pins

self adhesive pins aluminum solar panel mesh clip

all kinds of self locking washers, Dome caps.

50x50mm Galvainzed Based Rock Wool Insulation Pin With Self Locking Washer

Package Of Rock Wool Insulation Pin :

PIN LENGTH	CARTON SIZE	QTY/CARTON
38MM	41CMX28CMX17CM	1000PCS
50MM-65MM	41CMX28CMX17CM	500PCS
70MM-84MM	30CMX28CMX29CM	500PCS
90MM-120MM	30CMX30CMX30CM	500PCS
130MM-160MM	30CMX30CMX35CM	500PCS
170MM-203MM	30CMX30CMX28CM	250PCS
OTHERS	SUPPORT CUSTOM

50x50mm Galvainzed Based Rock Wool Insulation Pin With Self Locking Washer
